Divisible GasBlock ALU terminator
Provides an effective gas- and water-tight seal of a MicroDuct pathway with an existing cable inside. Easy to mount on MicroDucts from 5 to 20 mm (outer diameter) and reusable 5 times.
Caractéristiques
- Made from premium aluminum materials
- Gas- and water-tight seal: up to 10 bar (permanent)
- Multiple sizes are available for use with different cable diameters. Please state the cable diameter when ordering this product.
Détails techniques
| Description | Partie # | Quantité/caisse |
|---|---|---|
| Divisible GasBlock ALU terminator 5mm for cable 0,9 - 1,5mm | 20020427 | 100 |
| Divisible GasBlock ALU terminator 5mm for cable 1,4 - 2,0mm | 20020428 | 100 |
| Divisible GasBlock ALU terminator 5mm for cable 1,9 - 2,5mm | 20020429 | 100 |
| Divisible GasBlock ALU terminator 5mm for cable 2,4 - 3,0mm | 20020430 | 100 |
| Divisible GasBlock ALU terminator 7mm for cable 1,0 - 1,6mm | 20020431 | 100 |
| Divisible GasBlock ALU terminator 7mm for cable 1,5 - 2,1mm | 20020432 | 100 |
| Divisible GasBlock ALU terminator 7mm for cable 2,0 - 2,6mm | 20020243 | 100 |
| Divisible GasBlock ALU terminator 7mm for cable 2,5 - 3,1mm | 20020433 | 100 |
| Divisible GasBlock ALU terminator 7mm for cable 3,0 - 3,6mm | 20020434 | 100 |
| Divisible GasBlock ALU terminator 7mm for cable 3,5 - 4,1mm | 20020435 | 100 |
| Divisible GasBlock ALU terminator 10mm for cable 2,0 - 3,0mm | 20020436 | 50 |
| Divisible GasBlock ALU terminator 10mm for cable 2,9 - 3,9mm | 20020437 | 50 |
| Divisible GasBlock ALU terminator 10mm for cable 3,8 - 4,8mm | 20020438 | 50 |
| Divisible GasBlock ALU terminator 10mm for cable 4,7 - 5,7mm | 20020439 | 50 |
| Divisible GasBlock ALU terminator 10mm for cable 5,6 - 6,6mm | 20020244 | 50 |
| Divisible GasBlock ALU terminator 12mm for cable 2,0 - 3,0mm | 20020440 | 50 |
| Divisible GasBlock ALU terminator 12mm for cable 2,9 - 3,9mm | 20020441 | 50 |
| Divisible GasBlock ALU terminator 12mm for cable 3,8 - 4,8mm | 20020442 | 50 |
| Divisible GasBlock ALU terminator 12mm for cable 4,7 - 5,7mm | 20020443 | 50 |
| Divisible GasBlock ALU terminator 12mm for cable 5,6 - 6,6mm | 20020245 | 50 |
| Divisible GasBlock ALU terminator 12mm for cable 6,5 - 7,5mm | 20020444 | 50 |
| Divisible GasBlock ALU terminator 14mm for cable 6,0 - 7,0mm | 20020445 | 20 |
| Divisible GasBlock ALU terminator 14mm for cable 6,9 - 7,9mm | 20020446 | 20 |
| Divisible GasBlock ALU terminator 14mm for cable 7,8 - 8,8mm | 20020246 | 20 |
| Divisible GasBlock ALU terminator 14mm for cable 8,7 - 9,7mm | 20020447 | 20 |
| Divisible GasBlock ALU terminator 16mm for cable 8,0 - 9,0mm | 20020448 | 20 |
| Divisible GasBlock ALU terminator 16mm for cable 8,9 - 9,9mm | 20020449 | 20 |
| Divisible GasBlock ALU terminator 16mm for cable 9,8 - 11mm | 20020247 | 20 |
| Divisible GasBlock ALU terminator 20mm for cable 8,0 - 9,0mm | 20020450 | 20 |
| Divisible GasBlock ALU terminator 20mm for cable 8,9 - 9,9mm | 20020451 | 20 |
| Divisible GasBlock ALU terminator 20mm for cable 9,8 - 11,0mm | 20020248 | 20 |
| Divisible GasBlock ALU terminator 20mm for cable 11,0 - 12,0mm | 20020452 | 20 |
| Divisible GasBlock ALU terminator 20mm for cable 12,0 - 13,0mm | 20020453 | 20 |
